| Product Name: | PVC End Cap Gluing Machine | Production Speed: | 4 Pcs/min |
|---|---|---|---|
| Machine Weight: | 300kg | Machine Size: | 1405×950×1300mm(L×W×H) |
| Application: | PVC End Cap Gluing Machine | Warranty: | One Year |
| Service: | Engineer Available For Overseas Service | Voltage: | AC380V/220V |
| Highlight: | PVC End Cap Gluing Machine,4pcs/Min Gluing Machine |
||
4 Pcs/Min Car Air Filter Making Machine PVC End Cap Gluing Machine
1, General Description
This machine is applied to dispense PVC on the end caps of the heavy duty air filter.
2, Machine Specifications
| Product name | PVC End Cap Gluing Machine |
| Production speed | 4 pcs/min |
| Machine weight | 300kg |
| Machine size | 1405×950×1300mm(L×W×H) |
| Application | PVC end cap gluing machine |
| Warranty | One year |
| Service | Engineer available for overseas service |
| Voltage | AC380V/220V |
| The outer diameter of the end cap | ≤500mm |
| Gluing width | ≤50mm |
| Viscidity | ≤50000CP |
| Suitable adhesives | PVC filter adhesive(high temperature solidified adhesive) |
| Production capability | 4pcs/min |
| Power supply | 220V/50Hz |
| Main machine power | 500w |
| Working air pressure | 0.6MPa |
| The air pressure of the gluing pump | ≤0.45MPa |
| The working pressure of the gluing head | 4MPa |
| M/C weight | 300kg |
| M/C size | 1405×950×1300mm(L×W×H) |
3, Machine Features
1, This machine can glue evenly with wide using range.
2, Using the double sealing modes, to make the nozzle break off glue thoroughly after gluing.
3, The auto mover system push the glued products into the production line automatically to avoid affecting the product quality while transferring.
4, Adopts the excellent import pump, ensure gluing accurately.
FAQ:
Q: Are you the factory or trading company?
A: We are the first manufacturer of filter/application from 1990.
Q: What is your Minimum Order Quantity of your Product?
A: Normally the MOQ is 1 set;
Q: What's your payment term?
A: Usually, TT, Paypal, Alpay, Wei Xin, western union, can be selected according to your convenience
Q: What's your after-sales service?
A: Free online Technology Services 24h hours or engineers are available to serve machines overseas but travel cost will be born by your side;
Q: How Arrive to the factory?
A:If you fly, you can go to zhengding international airport. If you take the train, you can go to hengshui railway station. We will pick you up when you arrive.
